HiVi C3N-III 3" Paper Cone Full-Range Driver

HiVi's C3N-III is a magnetically shielded 3" paper cone driver. This driver is best used in a small sealed enclosure, and can be used in magnetically sensitive areas.

The ideal frequency bandwidth for this driver would be 100 Hz to 10,000 Hz.

Quantity Unit discount You Save
4 10% € 6.14
8 15% € 18.41

(0)
3" | 8 Ω | 15 W

Brand



Parameters:

  • Nominal Impedance (Z)(Ω) : 8
  •  Resonance Frequency (Fs)(Hz) : 130
  •  Nominal Power Handling (Pnom)(W) : 15
  •  Max Power Handling (Pmax)(W) : 30
  •  Sensitivity (2.83v/1m)(dB) : 84
  •  Weight (M)(Kg) : 0.53
  •  VC Diameter (mm) : 20
  •  DC (Re)(Ω) : 6.5
  •  VC Length (H)(mm) : 8.1
  •  VC Former : SV
  •  VC Frame : Kapton
  •  Magnet System : Shielded
  •  Magnet Former : Ferrite
  •  Force Factor (BL)(N/A) : 2.98
  •  Gap Height (He)(mm) : 3
  •  Linear Excursion (Xmax)(mm) : 2.55
  •  Suspension Compliance (Cms)(uM/N) : 671
  •  Mechanical Q (Qms) : 3.864
  •  Electrical Q (Qes) : 1.269
  •  Total Q (Qts) : 0.955
  •  Moving Mass (Mms)(g) : 2.057
  •  Effective Piston Area (Sd)(m2) : 0.003
  •  Equivalent Air Volume (Vas)(L) : 0.869
  •  Cabinet Type : Sealed
  •  Recommended Box Volume(Vb)(L) : 2
  •  Tuning Frequency(Fb)(Hz) : ---
  •  -3dB Cut-Off Frequency(F3)(Hz) : 80
Diameter
3"
Impedance
8 Ω
Power
15 W
Series
HIVI C/E
Material
Paper
